Small power servo drives

Author: admin Viewed: 6590Close

2017-04-25 14:53:43

  •




    Synmot drives adopt the special digital processing DSP of motor and the newest IGBT module, which have the advantages of fast dynamic response, high reliability, complete function and convenient operation. With high speed and low magnetic control function, it can effectively extend the range of motor operation, and the system can work normally at very low voltage


    Product features:
      Advanced control algorithm, support online control parameter setting and adjustment
      Support of torque control, speed control, position control
      Support ModBus, CANopen support RS-485 and EtherCAT industrial fieldbus
      Built-in brake unit
      User can preset the speed / time curve
      Intelligent thermal management technology, to ensure the long-term stable operation of the electric motor and drive
      High precision of current and voltage detection, can accurately and quickly achieve perfect protection




  • Sepcifications of SM10

    ModelInput voltageRated powerRated currentMax currentMotor capacityBraking resistor
    VackWAAkWΩ
    SM1X-40BB
    1PH/3PH
    AC220V
    ﹣15%-+10%
    (50/60Hz)
    0.403.07.10.40-
    SM1X-60BB 0.603.56.30.60
    SM1X-75BB0.754.08.50.75
    SM1X-10CB1.006.09.91.00
    SM1X-15CB1.508.012.71.50
    SM1X-22CB2.2011.019.82.20
    SM1X-30CB3.0014.032.53.00≥100
    SM1X-44CB4.4017.032.54.00
    SM1X-55CB5.5024.043.25.50≥70
    SM1X-30CC
    3PH
    AC380V
    ﹣15%-+10%
    (50/60Hz)
    3.008.515.33.00≥100
    SM1X-44CC4.4012.021.64.00
    SM1X-55CC5.5014.025.25.00≥70
    SM1X-75CC7.5017.531.57.50
    SM1X-11DC11.0026.048.611.00
    Drive current test conditions: PWM frequency 6kHz       【V2.0】

    Model

    Mounting hole

    Dimensions

    Mounting hole size

    Weight

    Type

    W1

    H1

    H

    H2

    W

    D

    R

    Kg

    SM10-40BB

    40

    200

    176

    222

    78

    180

    Φ5

    2.0

    A

    SM10-75BB

    SM10-10CB

    SM10-15CB

    40

    200

    176

    222

    90

    180

    Φ5

    2.5

    A

    SM12-60BB

    72

    170

    180

    180

    83

    143

    Φ5

    1.6

    B

    SM12-75BB

    SM12-10CB

    SM12-15CB

    SM12-22CB

    45

    190

    182

    208

    84

    192

    Φ6

    2.0

    A

    SM12-30CC

    102

    215

    225

    225

    114

    197

    Φ6

    4.0

    B

    SM12-44CC

    SM12-55CC

    113

    280

    295

    295

    132

    227.5

    Φ6

    6.5

    B

    SM12-75CC

    SM12-11DC






  • SM10 servo drive
